5 Tons Truck Crane

Rated Lifting Weight: 5000 kgs
Max Lifting Height: 22 m
Max Suspension Arm: 25m or 30m
Outrigger: 5 hydraulic outrigger
Hydraulic Pump: Single
Outrigger Telescopic Length: 1.5 m

EMAIL

The specification of 5 tons Truck Crane

Chassis Model	Faw Jiefang, Dongfeng Dolica or FOTON FORLAND
Engine	QuanChai
Gearbox model	WLY 5 Speed Gearbox or 7JS450 7 Speed Gearbox
Tire	650-R16
Suspension Arm Type	5m-5 sections or 5m-6 sections
Engine Powe	97KW (132HP), 83KW (115HP) or 96KW (130HP)
Slewing Mechanism	Vertical Type with Balancing Valve
Protector	Biliateral Pilot-Controlled Valve
