SIZE: 5100*1350*2580 mm
Overall Operating Weight: 2000 KGS
Max. Digging Depth: 1400 mm
Max Digging Radius: 2000 mm
Digging Bucket Width: 350 mm
Max Digging Power: 25 KN
Loader Max Dumping Height: 2200 mm
Loader Bucket Width: 1300 mm
Breakout Force: 28 KN
Engine: 25 kw and 2400 r/min
Specification of Backhoe loader
| Model | LC 08-12 |
| Wheel base | 1910 mm |
| Wheel track | 1100 mm |
| Min. Ground Clearance | 250 mm |
| Pressure of the system | 16 MPa |
| Max.Speed | 20 Km/h |
| Max. climbing angle | 25° |
| Min. turning radius | 3000 mm |
| Tires | 825-16 |
| Fuel tank | 20 L |
Main features:
1. The whole machine has a compact structure and a reasonable layout.
2. Beautiful appearance, reasonable humanized design,
3. The performance of the whole machine reaches the advanced level at home and abroad, and the hydraulic system adopts a well-known domestic brand.
4. The shovel ensures that the original loading function is not affected. The excavation part is folded as a counterweight, and the loading part is used as a chassis support during excavation. The two parts do not affect each other and can also help each other. The excavator is designed in the form of a slide, which has the advantages of folding side excavation and free sliding.
The whole machine can be equipped with various auxiliary tools according to user needs
